It’s all a matter of application – with TS 5000 SoftClose door closers

TS 5000 SoftClose door closers are a further development of the proven TS 5000 overhead door closer with guide rail, especially for installation situations with changing pressure levels. On the one hand, it impresses with exceptionally convenient and fast setting of the closing speed. On the other hand, it closes doors safely and quietly, even in difficult conditions such as wind and varying air pressures acting on the door leaf. This function is now available for all types of installation. Up to now, the applications have included door leaf installation hinge side and transom installation opposite hinge side. Now, the TS 5000 L SoftClose can also cover door leaf installation opposite hinge side and transom installation hinge side.

The highlights of the TS 5000 SoftClose door closers

  • Efficiency: Simple installation with no disruption to operations and exceptionally fast and variable setting of the door closer from the front.
  • Safety: Reliable closing that complies with all fire and building protection provisions – including doors with access authorisation.
  • Comfort: Doors close quietly in noise-sensitive environments – including in changing pressure levels.
  • Design: Usual slim GEZE design for simple retrofitting.

Technical data for door closer

Product features/Functions TS 5000 SoftClose door closer TS 5000 L SoftClose door closer
Closing force acc. to EN 1154 2 – 6 3-6
Leaf width recommended up to 1400 mm 1400 mm
Identical design DIN left and DIN right
Product tested in accordance with Door closer tested acc. to EN 1154 Door closer tested acc. to EN 1154
Suitability for fire protection doors
Mounting plate with hole pattern in accordance with EN1154 Supplement
Length 287 mm 287 mm
Overall depth 47 mm 47 mm
Height 60 mm 60 mm
Closing force adjustable Yes, with variable adjustment Yes, with variable adjustment
Closing speed adjustable
Latching action adjustable Yes, via valve Yes, via valve
Latching action speed integrated Yes, via valve to brake or accelerate the door between 15° und 0°
Back check integrated Yes, hydraulically adjustable Yes, hydraulically adjustable
Closing force adjustment position Front Front
Visual closing force display
Safety valve to prevent wilful damage
Thermo-constant valves
Type of installation Door leaf installation hinge side, transom installation opposite hinge side Door leaf installation opposite hinge side and transom installation hinge side
● = yes | ○ = optional
